incuART™ S
Giving the best results for your cell culture, the incuART™ family has been designed to deliver superior quality using advanced sensor technology that constantly surveys and adjust
Scientific Studies
Documents
| Model | incuART S – 6 chamber model |
| Temperature Features | |
| Temperature Control Range | ambient to 40°C |
| Individual Temperature Control | 0.1°C steps |
| Temperature Uniformity | ±0.1°C @ 37°C and @ 25°C ambient temperature |
| Temperature Sensors | 10 x PT1000 |
| pH features | |
| pH Range | N/A |
| pH Availability | N/A |
| pH measurement accuracy | N/A |
| pH resolution | N/A |
| Gas mixing features | |
| CO2 range | 0-20% CO2 |
| CO2 control resolution | ±0.1% CO2 |
| CO2 sensor type | Dual channel Infrared CO2 Sensor |
| CO2 consumption | < 3 l /hour |
| O2 range | 1-21% O2 |
| O2 control resolution | ±0.1% O2 |
| O2 sensor type | Fuel Cell – Medical Certified |
| N2 consumption | < 15 l/hour |
| # of gas Inputs | Gas inputs – 100 % CO2, 100 % N2, premixed |
| External logging & alarms | |
| Web Interface | requires static IP address only & VPN access – Android App available |
| SMS Alarm | Yes |
| E-mail alarm | Yes |
| Automatic relay alarm | Yes |
| Touch Screen Display | 8.9” |
| Bar-code scanner ID | 2D patient ID bar-code (optional) |
| Exterior Dimensions | 22.8″ W x 22.8″ D x 9.4″ H (580 mm x 580 mm x 240 mm) |
| Exterior Cabinet Construction | Powder Coated Aluminum |
| # of Chambers | 6 standard |
| External PT1000 sensors | 6 ports available for external monitoring (on request) |
| External gas monitoring system | 1 valve controlled port available |
| Chamber Dimensions | 6.2″ x 3.9″ (16 cm x 10 cm) – Falcon & Nunc compatible |
| Electrical | 110 – 230 VAC 50/60 Hz 3.5A |
| Shipping Weight | 77 lbs. (35 kg.) |
| Note!Specifications are subject to change without notice!All sensor data are measured @ sea level and normal average atmospheric pressure. | |
